Distillation Units Borosilicate Glass

All glass distillation units continue to be the most effective, economic method of producing ultra pure water for laboratory use.

By contrast de-ioniser are only effective in removing those substances which are ionized. Further the resins contribute organic impurities to water and an ideal environment for bacterial growth in course of time.

These distillation units are designed to produce a distillate of consistent purity. The unit consists of horizontal borosilicate boilers, condensers and quartz heater. All parts are replaceable.

Innovative Design

The newly developed quartz heater is advantageous than chromium plated heaters used by other manufacturers.
Chromium plated heaters react with acids during cleaning process.

Quartz heaters do not react with acids or water during cleaning or at elevated temperature unlike metallic ones.
Quartz heaters are easy to assemble and dismantle, unlike metallic ones which are bulky.

Advantages​

• Compact, simple to use.
• Economical and ideal for colleges and general laboratory use.
• Powder coated stand for rust free operation.
• Provision for easy cleaning of boiler.

MODEL No.1.5L4.0 L
Dist. Water Output cap. (Approx)1.5 lt/hr.4 lt/hr
Electrical requirements230-250 volts single phase 1.5 kw Quartz heater230-250 volts single phase 3 kw Quartz heater
Cooling water consumption50 lt/hr.60 lt/hr.
Biological ActivityPyrogen FreePyrogen Free
pH7-Jun7-Jun
